Zinc Plated Sheet 200mm Morris Compression Coupling

  • 1
  • 2
  • 3

Brand Name : AWD

Model Number : CP100-200mm

Place of Origin : China

MOQ : 100pcs

Price : negotiation

Payment Terms : L/C, T/T,

Supply Ability : 3000 per month

Delivery Time : according to order quantity

Packaging Details : The size of our wooden box is 110cm*110cm*110cm we will carefully give our packaging suggestion or packing according to your requirement.

Material : zinc plated sheet

Usage : Pipe Clamp

Standard or nonstandard : Standard

Application : Connection

Color : Zn plated

product name : Pipe Coupling

Contact Now

Pipe Coupling

Product deteal:



Due to the differences of application environment and materials used. We can customize according to the quantity of products.



Pipe Couplings are 150mm or 200mm long, 3 or 4 bolt couplings designed for vacuum or pressure conveying systems for heavy concentration particles.

The Eurac HL & H Series Pipe Couplings are 150mm or 200mm long, 3 or 4 bolt couplings designed for vacuum or pressure conveying systems for heavy concentration particles.
The size 38-152mm suitable for all pneumatic and vacuum conveying operations.
Standard build comes with outside skin in galvanised steel, SS304 Conductivity Strip, Zinc Plated Bolts and White silicone gasket or rubber gasket.



feature:



The Morris pipe coupling used to join pipe and tubing for pneumatic conveying systems.

1. Static conductive grounding strip is standard

2. Gasket materials: silicone and others

3. Standard construction is galvanized steel

4. Pipe and tube sizes 38 mm to 114 mm







Product Name



Morris compression coupling



Shell Material



Stainless steel 430/304,Zinc Palted sheet



Middle layer material



stainless steel 304 sheet



Lining material



Rubber sheet/ Silicone Sheet



Size



38mm/48mm/50mm/63mm/76mm/89mm/102mm/127mm/152mm...



Length



100mm/130mm/150mm/200mm



Material of bolt and nut



Galvanized steel or stainless steel



OEM



If you need to customize logo, please let us know in advance



Package



Plastic independent packaging + carton

Zinc Plated Sheet 200mm Morris Compression CouplingZinc Plated Sheet 200mm Morris Compression Coupling

Zinc Plated Sheet 200mm Morris Compression Coupling
